1 Installing the Router
Use default boot line parameters: e=192.168.1.1:ffffff00 h=192.168.1.100 g= r=f f= i= d=3 p=0
DHCP running
Board IP address
Host IP address
Gateway IP address
Run from flash/host (f/h)
Default host run file name
Default host flash file name
Boot delay (0-9 seconds)
Boot image (0=latest, 1=previous) : 0
Board Id (0-1)
Number of MAC Addresses (1-32)
Base MAC Address
PSI Size (1-64) KBytes
Main Thread Number [0|1]
DHCP running
web info: Waiting for connection on socket 0.
• The device is now in BOOT mode with the default IP configuration from BOOT (IP address 192.168.1.1 and mask
255.255.255.0).
•
Note
In BOOT mode, only the LAN1 connector is available.
Accessing the BOOT menu from the console without using the RST button
It is also possible to access the BOOT menu without using the RST button if you have access to the device's local
console. To do this, you need to simultaneously press the CTRL and T keys during the start up process when the
text "***Press CTRL+T to stop DHCP and break into CFE menu ***" or "Press CTRL+T to stop auto run (X
seconds)***" appears, and before the indicated seconds run out. In this way the C.I.T. start up cancels and the
device pauses in the BOOT prompt: "CFE>" . From this menu, you can access all the BOOT menu commands. Below
you can see an example of a H1+/H1+GE start up:
CFE version 1.0.37-102.9-02 for BCM96368 (32bit,SP,BE)
Build Date: Fri Feb 12 17:20:44 CET 2010 (gjimenez@orion)
Copyright (C) 2000-2008 Broadcom Corporation.
Parallel flash device: name AM29LV320MT, id 0x2201, size 16384KB
CPU type 0x2A031: 400MHz, Bus: 160MHz, Ref: 64MHz
CPU running TP0
Total memory: 67108864 bytes (64MB)
Boot Address 0xb8000000
Board IP address
Host IP address
Gateway IP address
Run from flash/host (f/h)
Default host run file name
Default host flash file name
Boot delay (0-9 seconds)
Boot image (0=latest, 1=previous) : 0
Board Id (0-1)
Number of MAC Addresses (1-32)
Base MAC Address
PSI Size (1-64) KBytes
Main Thread Number [0|1]
22
: 192.168.1.1:ffffff00
: 192.168.1.100
:
: f
:
:
: 3
: 96369H1P
: 4
: 00:a0:26:74:00:80
: 24
: 0
: 192.168.1.1:ffffff00
: 192.168.1.100
:
: f
:
:
: 3
: 96369H1P
: 4
: 00:a0:26:74:00:80
: 24
: 0
