Teldat H1+ Installation Manual page 35

Teldat S.A.
SIM
CONNECTOR
ANTENNA
Wireless LAN Interface
STANDARDS
SPEED
CONNECTOR
USB Interface
3G USB MODEMS
SPEED
CONNECTOR
Configuration Interface
LOCAL TERMINAL
CONNECTOR
Power Supply
INPUT VOLTAGE
INPUT CURRENT
JACK
INTERNAL PIN
External power supply
INPUT VOLTAGE
INPUT CURRENT
INPUT FREQUENCY
Dimensions and weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
Environmental Specifications
AMBIENT TEMPERATURE
Teldat H1+/H1+GE
Internal and External. Compatible with 1.8V and 3V.
RF SMA Female
Depends on the type of Wireless WAN module. Please see the catalog of anten-
nas for Cellular interfaces.
Please see the manual on Wireless LAN
Please see the manual on Wireless LAN
2 RF Reverse SMA Male
Check the Teldat webpage http://www.teldat.com to obtain the list of 3G USB mo-
dems that can be supported.
The interface complies with USB 2.0 (480 Mbps) standard: final speed depends
on the type of 3G USB modem used.
USB Type A
V.24 9.600-8-N-1- without flow control.
RJ45 female on the rear part of the device.
+12 V DC
1200 mA
5,5 mm
2,5 mm
100-240 V AC
600 mA
50-60 Hz
Desktop
220 x 220 x 30 mm
0.9 kg
OPERATING NORMALLY: 0 °C to 45 °C
STORED: -30 °C to 85 °C
Technical Information
31
