1 Installing the Router
Note
Some devices leave the factory with a customized configuration for a specific client. This personaliza-
tion can mean that the default configuration is different from the one shown above.
This initial configuration allows you to access the device configuration console through the Telnet IP protocol. To do
this, carry out the following steps:
• Configure the IP terminal Ethernet interface (normally a PC) with IP address in the range of [192.168.1.2,
192.168.1.254] and mask 255.255.255.0. E.g. 192.168.1.2, 255.255.255.0.
• Connect the IP terminal Ethernet interface to any of the Teldat H1+/H1+GE router Ethernet Switch ports
(connectors LAN 1..4) through the Ethernet cable (RJ45) supplied with the device.
• Start a Telnet session from the IP terminal towards IP address 192.168.1.1 ( Teldat H1+/H1+GE router default ad-
dress).
• The default configuration does not request access credentials (user/password) to access the console.
For further information on how to fully configure the device, please see the manuals included on the CD supplied with
the Teldat H1+/H1+GE router.

1.2.6 Installing the SIM card

The Teldat H1+/H1+GE has a Wireless WAN interface, which means that at least one SIM card must be inserted in
the device so it is operative. There are certain services (CDMA) from some operators in several countries that do not
require SIM cards.
The Teldat H1+/H1+GE has two SIM trays. One SIM tray is accessible from the device exterior and the other is loc-
ated inside the device.
In installations where a SIM card is required, you must always install at least one SIM card. In these devices, when
only one SIM card is going to be used, this can be installed in either of the two SIM trays, but you must bear in mind
that the router must be correctly configured so the correct tray is selected.
Warning
This device is compatible with a 1.8V and a 3V SIM. Do not install a SIM that doesn't support
these voltages.
Warning
Never install the SIM card when the device is switched on.
Always disconnect the device from the main power supply before inserting the internal SIM.
Always disconnect the device before removing the casing to get to the internal SIM.
When inserting the SIM card, please protect yourself against electrostatic discharges (ESD).
Do not touch the SIM card connectors.
1.2.6.1 Installing the internal SIM
To access the internal SIM, you need to dismantle the upper outer casing. To do this, unscrew the four holding
screws that are located on the underside of the device. The SIM card is positioned just below the WWAN Main an-
tenna connector which is located on the main printed circuit board.
