Page 1: Installation Manual
Manual Teldat SA APR222ac Installation Manual Copyright© Teldat Dm647-I Version 1.3 2/2019 Teldat SA APR222ac... - Page 2 This publication is subject to change. Teldat SA offers no warranty whatsoever for information contained in this manual. Teldat SA is not liable for any dir- ect, indirect, collateral, consequential or any other damage connected to the delivery, supply or use of this manual.
-
Page 3: Table Of Contents
Table of Contents Teldat SA Table of Contents Chapter 1 Introduction ........1 Chapter 2 Installation. - Page 4 Table of Contents Teldat SA Access Options........
-
Page 5: Chapter 1 Introduction
Password If you already know how to configure Teldat devices and you want to get started right away, all you really need to know is the preset user name and password. User Name: admin... -
Page 6: Chapter 2 Installation
2 Installation Teldat SA Chapter 2 Installation Note Please read the safety notices carefully before installing and starting up your device. These are sup- plied together with the device. Refer to chapter Technical data on page 14. 2.1 Setting up and connecting Note The device can be fitted with various antenna systems. - Page 7 Use just one of the ports (LAN1 or LAN2). The second port is used to cascade a number of devices. If you use both Ethernet connections on the same switch, loops may form. (5) Power connection The APR222ac is powered by a 110 V or 24 V nominal DC power source, depending on the model. APR222ac...
-
Page 8: Anticorrosion Measures To Protect The Metal Parts Of The Device During Transportation, Storing Or At Its Final Location
As far as the metal housing is concerned, the APR222ac was designed to be placed in an enclosed location, protec- ted from bad weather; never to be exposed or subject to these or any other extreme environmental conditions. -
Page 9: Cleaning
Make sure that no moisture can enter the device and cause damage. 2.4 Support information Teldat, S.A. offers a technical support service. The device software can be regularly updated for maintenance pur- poses and to add new features. Contact information: Web: www.teldat.com... -
Page 10: Chapter 3 Basic Configuration
3 Basic configuration Teldat SA Chapter 3 Basic configuration To configure the basic settings in your device, use Dime Manager (IP address assignment) and GUI (other configur- ation steps). A step-by-step explanation is included below. A detailed online help system gives you extra support. -
Page 11: Software Update
Teldat SA Note All Teldat devices are delivered with the same username and password. This means they are not pro- tected against unauthorized use as long as the password remains unchanged. Make sure you change said password to stop your device from being unduly accessed! -
Page 12: Configuring A Pc
3 Basic configuration Teldat SA Access Point mode If you run your device in Access Point mode, you can set up the required wireless networks. To do this, you need the following data: Configuration of a wireless network Access data... -
Page 13: Ip Configuration
3 Basic configuration Teldat SA 3.4 IP configuration In the ex works state, your device is configured in DHCP Client mode and dynamically receives an IP address if you run a DHCP server in your network. Otherwise, connect your device directly to the configuration PC and use fallback IP address 192.168.0.252. -
Page 14: Modify System Password
3.5 Modify system password All Teldat devices are delivered with the same username and password. As a result, and for as long as said pass- word remains unchanged, they are not protected against unauthorized use. Make sure you change the password to... -
Page 15: Setting Up A Wireless Network
3.7 Software Update The range of functions of Teldat devices is continuously being extended. Teldat SA makes them available to you free of charge. Checking for new software versions and the installation of updates can be carried out easily via GUI. An Internet connection is necessary to perform an automatic update. - Page 16 Teldat SA The device will now connect to the Teldat SA download server and check whether an updated version of the system software is available. If so, your device will be updated automatically. When installation of the new software is com- plete, you will be invited to restart the device.
-
Page 17: Chapter 4 Reset
4 Reset Teldat SA Chapter 4 Reset If the configuration is incorrect or your device cannot be accessed, you may use the Reset button to reset the device to the ex works standard settings. All existing configuration data will be erased! To do this, follow these steps: (1) Keep the Reset button pressed for approximately 30 seconds. -
Page 18: Chapter 5 Technical Data
Buttons Reset. To ensure safe operation, APR222ac devices have a protective earth connection. The minimum cross-section of the earth lead should be 2.5 mm². The distance between the device and the earth connection should be as short as pos- sible. -
Page 19: Leds
The LEDs show the radio status, radio activity and LED states of your device. The LED states are made up of LED combinations, further explained in detail in this chapter. The LEDs on the APR222ac device are arranged as follows: APR222ac Fig. -
Page 20: Pin Assignments
5 Technical data Teldat SA Status LED (green). WLAN1 / WLAN2 LED (green). 5.4 Pin Assignments 5.4.1 Ethernet interface Your device has two Ethernet interfaces. These are used to connect individual PCs or other switches. The connection is made via an 8-pole female M12 socket. -
Page 21: Frequencies And Channels
You must ensure that your network complies with these restrictions and requirements. The requirements for any country may change.Teldat SA recommends that you check with local author- ities what the latest status of their national regulations is for both 2.4 and 5 GHz wireless LANs. -
Page 22: Chapter 6 Access And Configuration
6 Access and configuration Teldat SA Chapter 6 Access and configuration This chapter describes the access and configuration options. 6.1 Access Options • Via your LAN. 6.1.1 Access via LAN Accessing via one of the Ethernet interfaces allows you to open GUI in a web browser (for configuration purposes) and to access your device via Telnet or SSH. - Page 23 6 Access and configuration Teldat SA in the SNMP shell of your device. (2) Follow the provisions set forth in Logging in for Configuration on page 20. 6.1.1.3 SSH In addition to the unencrypted and potentially viewable Telnet session, you can also connect to your device via an SSH connection.
-
Page 24: Login
Caution All Teldat devices are delivered with the same username and password. As a result, and for as long as said password remains unchanged, they are not protected against unauthorized use. Section Modify system password on page 10 shows how to change passwords. -
Page 25: Configuration Options
6 Access and configuration Teldat SA GUI (Graphical User Interface) Log in via the HTML surface as follows: (1) Enter your user name in the User field of the input window. (2) Enter your password in the Password field of the input window and confirm with Return (or click on the Login button). - Page 26 6 Access and configuration Teldat SA Fig. 11: home page 6.3.1.1 Calling up GUI (1) Make sure the device is connected and switched on and that all necessary cables are correctly connected (see Technical data on page 14). (2) Check the settings of the PC you want to use to configure your device (see Configuring a PC on page 8).
- Page 27 6 Access and configuration Teldat SA Fig. 12: Areas of the Header Fig. 13: header GUI header Menu Position Language: English is the only language currently available. View: Select the desired view from the dropdown menu. Standard and SNMP browsers can be selected.
- Page 28 6 Access and configuration Teldat SA Fig. 15: Menus The Save configuration button is found in the navigation bar. If you save the current configuration, you can save it as the boot configuration and file the previous boot configura- tion as a backup.
- Page 29 6 Access and configuration Teldat SA Main configuration window The sub-menus generally contain several pages. These are called using the buttons at the top of the main window. If you click on a button, the window is opened with the basic parameters. You can extend this by clicking on the Ad- vanced Settings tab, which displays the additional options.
- Page 30 6 Access and configuration Teldat SA Symbol Position Triggers a WLAN bandscan. Displays the next page in a list. Displays the previous page in a list. You can select the following operating functions in the list view: GUI list options...
- Page 31 6 Access and configuration Teldat SA The following configuration options are available: GUI configuration elements Menu Position Input fields e.g. empty text field Text field with hidden input Enter the data. Radio buttons e.g. Select the corresponding option. Checkboxes e.g. activation by selecting checkbox...
-
Page 32: The Setup Tool For Experts
• The menu line contains a navigation aid detailing your current position in the Setup Tools menu system. The sys- tem name of your device is also displayed. This is especially helpful if you are using several Teldat devices with different system names. - Page 33 6 Access and configuration Teldat SA Key combination Meaning Tabulator Jumps to the next field menu. Return key Opens a sub-menu or activates a command (e.g. SAVE). up or down (arrow keys) Goes to the next or previous field in the menu (works with VT 100 emulation when using a terminal program).
- Page 34 6 Access and configuration Teldat SA 6.3.2.3 Searching Lists Some Setup Tool menus contain lists with several entries (e.g. the VSS configuration menu, which lists all wireless networks): Fig. 19: Setup Tool search An incremental search function is provided (useful when searching for an item in very long lists).
-
Page 35: Snmp Shell
6 Access and configuration Teldat SA 6.3.2.4 Changing the Password The following process applies to all passwords on your device: the access passwords for user names admin, read and write, the HTTP password, the PPP password and the provider password. - Page 36 6 Access and configuration Teldat SA • BOOTmonitor mode. • Normal mode. After some self-tests have been successfully carried out in the start mode, your device reaches the BOOTmonitor mode. The BOOTmonitor prompt is displayed if you are serially connected to your device.
