Technical Information
A.3.8 Power connector
PIN
Internal
External
A.4 Technical Specifications
Hardware Architecture
PROCESSORS
MEMORY
STORAGE UNIT
LAN Interface
PROTOCOLS
SPEED
CONNECTOR
WAN Interface
STANDARDS
SPEED
CONNECTOR
Wireless WAN Interface
STANDARDS /
SPEED
30
ANT
POSITIVE
NEGATIVE
Broadcom BCM6369
64 Mbytes in SDRAM
FLASH Memory (16 Mbytes)
Ethernet (802.3)
SWITCH 10/100 Mbps (BaseT)
RJ45 female
Ethernet (802.3)
10/100/1000 Mbps (BaseT)
RJ45 female
• HSPA:
Triband Version: 850, 1900 and 2100 MHz
Dualband Version: 900 and 2100 MHz
Forward link up to 7.2 Mbps; reverse link up to 5.76 Mbps
• Universal Mobile Telecommunication System (UMTS) : Triband Version: 850,
1900 and 2100 MHz
Dualband Version: 900 and 2100 MHz
Forward link up to 2.0 Mbps; reverse link up to 384 kbps
• EDGE:
Quadband: 850, 900, 1800, and 1900 MHz
Forward link up to 236 kbps; reverse link up to 124 kbps
• GPRS:
Quadband: 850, 900, 1800, and 1900 MHz
Forward link up to 80 kbps; reverse link up to 42 kbps
