Warning
Laser Radiation. Do not use optical instruments directly or without proper protection. CLASS 1 LASER
PRODUCT.
The SFP modules to be installed in the card socket should be class 1 devices that comply with the IEC/
EN 60825-1:2007 standard.

3.7.3 WWAN Antenna Connection (Cell connector)

The Teldat Connect-KFPlus router has two SMA connectors in the rear panel and two SMA connectors in the side
panel that are not used on this router.

3.7.4 Connecting the GPS antenna

The Teldat Connect-KFPlus has an SMA connector in the rear panel that is not used on this router.

3.7.5 Wireless LAN internal antennas

The Teldat Connect-KFPlus has two integrated antennas for an internal Wireless LAN module covering both the 2.4
GHz and 5 GHz bands.
Antenna connectors
Fig. 12:

3.7.6 Connecting for Configuration

The Teldat Connect-KFPlus has a RJ45 female connector on the front panel (labeled "Aux.") that provides access
to the device's local console
For further information, please see
Aux. Connector
Fig. 13:

3.8 Installing the SIM card

The Teldat Connect-KFPlus router does not use SIM cards.
Teldat Connect-KFPlus
Connecting to the device on page 21.
