SmartNode 4740 Series (48–128 Ports) User Manual
• IP addresses and/or URL of SIP servers or Internet telephony services (if used)
• Login and password for PPPoE Access
• Login and Password for SIP based telephony services
• IP addresses of central TFTP server used for configuration upload and download (optional)

Software tools

The simplest way configuring the SN4740 Series is through
Alternatively you may use the Web interface in combination with a Web wizard to get your unit up and run-
ning. For more details, see the
The Command Line Interface is also supported for configuration, and can be accessed through Telnet /SSH.
Also see the Knowledgebase

Power source

If you suspect that your AC power is not reliable, for example if room lights flicker often or there is machinery
with large motors nearby, have a qualified professional test the power. Patton recommends that you include an
uninterruptible power supply (UPS) in the installation to ensure that VoIP service is not impaired if the power
fails.

Location and mounting requirements

The SmartNode SN4740 is intended to be placed on a desktop (or similar sturdy, flat surface) or in a 19-inch
equipment rack that offers easy access to cables. Allow sufficient space at the rear of the chassis for cable con-
nections. Additionally, you should consider the need to access the unit for future upgrades and maintenance.

Installing the SmartNode 4740

Install the SmartNode device as follows:
• Placing the device at the desired installation location (see section
• Installing the interface (see section
cables" on page 42)
• Installing the ground wire onto the grounding stud (see section
device's grounding stud"
• Installing the telephony cables (see section
on page 43)
• Installing the power cables (see section
page 43)
When you finish installing the SmartNode, go to Chapter 4,

Installing the SmartNode 4740

Wizard Portal.
for config snippets when configuring your device through CLI.
"Connecting the 10/100/1000Base-T Gigabit Ethernet LAN and WAN
on page 42
"Installing cables on the SmartNode device's FXS interface ports"
"Connecting the AC power cables or DC power source input"
Patton Cloud.
"Placing the SmartNode
"Installing a ground wire on the SmartNode
"Initial Configuration"
3 • SmartNode Installation
device")
on
on page 46.
41
