Using The Reset Button To Switch To A Backup Image - Patton SmartNode 4740 Series User Manual

SmartNode 4740 Series (48–128 Ports) User Manual
2. The POWER LED will begin a series of blink pattern starting with 1-blink, pause.
Table 32. Using the RESET button to switch to a backup image
LED Blink Pattern
1-blink, pause
2-blinks, pause
3-blinks, pause
3. Repeatedly pressing and releasing the RESET button will cycle through the blink patterns.
4. When you get to the 3-blink pattern that will erase the entire flash memory (see
RESET button. 10 seconds later, flash memory will be erased, then the device will boot.
5. Once booted up, the device will run using the "minimal-config":
#----------------------------------------------------------------#
# #
# Minimal configuration file #
# #
#----------------------------------------------------------------#
cli version 4.00
telnet-server
shutdown
ssh-server
no shutdown
web-server http
shutdown
web-server https
shutdown
context ip ROUTER
interface LAN
ipaddress LAN 192.168.200.10/24
ipaddress DHCP dhcp
port ethernet 0 0
bind interface ROUTER LAN
no shutdown
Very exceptional case—minimal config recovery
Boot normally
Switch to backup image, then Boot normally
Erase entire contents of flash memory (no exceptions), then boot.
Note Erasing flash memory also deletes previously pur-
chased and loaded software license keys.
F • Reset Button Functions
Action
table 32), release the
102
