SmartNode 4740 Series (48–128 Ports) User Manual
Table 15. Band Marked Color Code for Telco Connector C (128-port) (Continued)
Wire/Color Code
Main Color
Black
Slate
Yellow
Blue
Yellow
Orange
Yellow
Green
Yellow
Brown
Yellow
Slate
Violet
Blue
Violet
Orange
Violet
Green
Violet
Brown
Violet
Slate
FXS ports 0/72–0/95 (see

Connector D.

Table 16. Band Marked Color Code for Telco Connector D (128-port)
Wire/Color Code
Main Color
White
Blue
White
Orange
White
Green
FXS port
Tip and
Ring
Stripe
Slate Tip 15
Black Ring 15
Blue Tip 16
Yellow Ring 16
Orange Tip 17
Yellow Ring 17
Green Tip 18
Yellow Ring 18
Brown Tip 19
Yellow Ring 19
Slate Tip 20
Yellow Ring 20
Blue Tip 21
Violet Ring 21
Orange Tip 22
Violet Ring 22
Green Tip 23
Violet Ring 23
Brown Tip 24
Violet Ring 24
Slate Not Used
Violet Not Used
figure 30 on page 67 and
Tip and
Ring
Stripe
Blue Tip 1
White Ring 1
Orange Tip 2
White Ring 2
Green Tip 3
White Ring 3
Pair 50 Pin
Number Positions
Pair 15 40
15
Pair 16 41
16
Pair 17 42
17
Pair 18 43
18
Pair 19 44
19
Pair 20 45
20
Pair 21 46
21
Pair 22 47
22
Pair 23 48
23
Pair 24 49
24
Pair 25 50
25
(Not Used)
table 16).
Pair 50 Pin
Number Positions
Pair 1 26
1
Pair 2 27
2
Pair 3 28
3
D • Port pin-outs
SmartNode
Config-Port
Port 0/62
Port 0/63
Port 0/64
Port 0/65
Port 0/66
Port 0/67
Port 0/68
Port 0/69
Port 0/70
Port 0/71
SmartNode
Config-Port
Port 0/72
Port 0/73
Port 0/74
72
