SmartNode 4740 Series (16–32 Ports) User Manual
• IP addresses and/or URL of SIP servers or Internet telephony services (if used)
• Login and password for PPPoE Access
• Login and Password for SIP based telephony services
• IP addresses of central TFTP server used for configuration upload and download (optional)

Software tools

The simplest way configuring the SN4740 Series is through
Alternatively you may use the Web interface in combination with a Web wizard to get your unit up and run-
ning. For more details, see the
The Command Line Interface is also supported for configuration, and can be accessed through Telnet /SSH.
Also see the Knowledgebase

Power source

If you suspect that your AC power is not reliable, for example if room lights flicker often or there is machinery
with large motors nearby, have a qualified professional test the power. Patton recommends that you include an
uninterruptible power supply (UPS) in the installation to ensure that VoIP service is not impaired if the power
fails.

Location and mounting requirements

The SmartNode SN4740 is intended to be placed on a desktop or similar sturdy, flat surface that offers easy
access to cables. Allow sufficient space at the rear of the chassis for cable connections. Additionally, you should
consider the need to access the unit for future upgrades and maintenance.

Installing the SmartNode 4740

Install the SmartNode device as follows:
• Placing the device at the desired installation location (see section
• Installing the interface, telephony, ground wire, and power cables (see section
When you finish installing the SmartNode, go to Chapter 4,

Placing the SmartNode device

Install the SmartNode device in a 19-inch rack or place it on a desktop or similar sturdy, flat surface. Allow suf-
ficient space at the rear of the chassis for cable connections. Additionally, you should consider the need to
access the unit for future upgrades and maintenance.
CAUTION

Installing the SmartNode 4740

Wizard Portal.
for config snippets when configuring your device through CLI.
To prevent overheating and damaging the unit, proper ventilation
is required when placing the device; leave at least 2 inches (5
cm) to the left, right, front, and rear of the SmartNode device.
The device should be installed in a dry environment with suffi-
cient space to allow air circulation for cooling. Do not stack multi-
ple SmartNode devices directly on top of one another, and do not
place items on top of the device. If you will be installing equip-
ment above the SmartNode device, leave at least 2 inches (5
cm) of clearance between the devices.
Patton Cloud.
"Placing the SmartNode
"Installing cables"
"Initial Configuration"
3 • SmartNode Installation
device")
on page 30)
on page 33.
29
