SmartNode 4740 Series (48–128 Ports) User Manual
Table 5. Front and rear panel descriptions (RJ11 & RJ21 combo version)
Button/LEDs/Ports
RESET button
FXS Ports (RJ21)
Front Panel/Rear Panel Ports and LEDs
The reset button has several functions, as described in appendix F,
"Reset Button Functions"
Telco 50-pin analog ports located on the rear panel.
Description
on page 98.
