About this guide
This guide describes the SmartNode 4740 Series Analog High Density Gateway (48 to 128 ports) hardware,
installation and basic configuration. For detailed software configuration information refer to the
ware Configuration Guide
Audience
This guide is intended for the following users:
Operators
•
•
Installers
Maintenance technicians
•
Structure
This guide contains the following chapters and appendices:
Chapter 1
on page 15 contains what you need to quickly start using the SmartNode device.
•
•
Chapter 2
on page 19 provides information about SN4740 features and capabilities
•
Chapter 3
on page 39 provides quick start hardware installation procedures
•
Chapter 4
on page 46 provides quick-start procedures for configuring the SmartNode SN4740
Chapter 5
on page 52 contains information on contacting Patton technical support for assistance
•
Appendix A
on page 55 contains compliance and regulatory information for the SN4740
•
Appendix B
on page 57 contains specifications for the SN4740
•
Appendix C
on page 62 provides cable recommendations
•
Appendix D
on page 65 describes the SN4740's ports and pin-outs
•
Appendix E
on page 96 lists the factory configuration settings for SmartNode 4740
•
page 96 lists the factory configuration settings for SmartNode 4740 Series
Appendix F
on page 98 describes RESET button functions for the SmartNode 4740 Series
•
Appendix G
on page 103 provides license information that describes acceptable usage of the software pro-
•
vided with the SmartNode 4740 Series
For best results, read the contents of this guide before you install the SN4740.
and the available Knowledgebase, as well as the
Wizard
portal.
