SmartNode 4740 Series (48–128 Ports) User Manual

Placing the SmartNode device

Install the SmartNode device in a 19-inch rack or place it on a desktop or similar sturdy, flat surface. Allow suf-
ficient space at the rear of the chassis for cable connections. Additionally, you should consider the need to
access the unit for future upgrades and maintenance.
CAUTION

Connecting the 10/100/1000Base-T Gigabit Ethernet LAN and WAN cables

WARNING
WARNING
The SmartNode 4740 Series has automatic MDX (auto-cross-over) detection and configuration on the Ether-
net ports. Any of the two ports can be connected to a host or hub/switch with a straight-through wired cable.
1. Connect to the subscriber port of the broadband access modem (DSL, cable, WLL) to ETH 0/0.
2. Connect port ETH 0/1 to your LAN.
For details on the Ethernet port pin-out and cables, refer to
D, "Port pin-outs"
on page 65.

Installing a ground wire on the SmartNode device's grounding stud

1. Route the ground wire from a building ground connection to the SmartNode device.
WARNING
2. Connect the grounding wire to the grounding stud of the SmartNode device (see
3. Verify that the resistance of the ground path is less than 0.5 ohms.
Installing the SmartNode 4740
To prevent overheating and damaging the unit, proper ventilation
is required when placing the device; leave at least 2 inches (5
cm) to the left, right, front, and rear of the SmartNode device.
The device should be installed in a dry environment with suffi-
cient space to allow air circulation for cooling. Do not stack multi-
ple SmartNode devices directly on top of one another, and do not
place items on top of the device. If you will be installing equip-
ment above the SmartNode device, leave at least 2 inches (5
cm) of clearance between the devices.
Do not work on the system or connect or disconnect
cables during periods of lightning activity.
The Interconnecting cables shall be acceptable for external
use and shall be rated for the proper application with
respect to voltage, current, anticipated temperature, flam-
mability, and mechanical serviceability.
According to UL60950/IEC62368, a connection to earth
ground—using the grounding stud at the rear of the units
(see
figure 12
on page 26
power cross.
Appendix C, "Cabling"
)
—is required to protect against
3 • SmartNode Installation
on page 62 and
Appendix
figure 12
on page 26).
42
