SmartNode 4740 Series (48–128 Ports) User Manual
Table 19. Band Marked Color Code for Telco Connector A (96-port) (Continued)
Wire/Color Code
Main Color
Red
Blue
Red
Orange
Red
Green
Red
Brown
Red
Slate
Black
Blue
Black
Orange
Black
Green
Black
Brown
Black
Slate
Yellow
Blue
Yellow
Orange
Yellow
Green
Yellow
Brown
Yellow
Slate
Violet
Blue
Violet
Orange
Violet
Green
FXS port
Tip and
Ring
Stripe
Blue Tip 6
Red Ring 6
Orange Tip 7
Red Ring 7
Green Tip 8
Red Ring 8
Brown Tip 9
Red Ring 9
Slate Tip 10
Red Ring 10
Blue Tip 11
Black Ring 11
Orange Tip 12
Black Ring 12
Green Tip 13
Black Ring 13
Brown Tip 14
Black Ring 14
Slate Tip 15
Black Ring 15
Blue Tip 16
Yellow Ring 16
Orange Tip 17
Yellow Ring 17
Green Tip 18
Yellow Ring 18
Brown Tip 19
Yellow Ring 19
Slate Tip 20
Yellow Ring 20
Blue Tip 21
Violet Ring 21
Orange Tip 22
Violet Ring 22
Green Tip 23
Violet Ring 23
Pair 50 Pin
Number Positions
Pair 6 31
6
Pair 7 32
7
Pair 8 33
8
Pair 9 34
9
Pair 10 35
10
Pair 11 36
11
Pair 12 37
12
Pair 13 38
13
Pair 14 39
14
Pair 15 40
15
Pair 16 41
16
Pair 17 42
17
Pair 18 43
18
Pair 19 44
19
Pair 20 45
20
Pair 21 46
21
Pair 22 47
22
Pair 23 48
23
D • Port pin-outs
SmartNode
Config-Port
Port 0/5
Port 0/6
Port 0/7
Port 0/8
Port 0/9
Port 0/10
Port 0/11
Port 0/12
Port 0/13
Port 0/14
Port 0/15
Port 0/16
Port 0/17
Port 0/18
Port 0/19
Port 0/20
Port 0/21
Port 0/22
