SmartNode 4740 Series (48–128 Ports) User Manual
Table 5. Front and rear panel descriptions (RJ11 & RJ21 combo version)
Button/LEDs/Ports
POWER LED
VoIP LED
AUX1 LED
AUX2 LED
USB 2.0 Port
Console port
FXS Port Status
LEDs
FXS Ports
ETH 0/0 & ETH 0/1 Auto-MDX Gigabit Ethernet port, RJ-45, connects the unit to an Ethernet
ETH 0/0 & ETH 0/1
ports ACT LED
(green)
ETH 0/0 & ETH 0/1
ports GIG LED
(yellow)
Front Panel/Rear Panel Ports and LEDs
When lit, indicates power is applied. Blinks fast during bootloader phase
and blinks slow during the boot process. Constantly lit when the system
is up and running.
When lit, indicates the SmartNode device has at least one successful
registration to a SIP server, or a SIP device has successfully registered
to the SmartNode device.
Off indicates the unit is not configured or registered, or has no active
directly routed VoIP connection.
On when connected to Patton Cloud
Auxiliary LED for future use
USB 2.0 host port is used to connect a USB 3G/4G Cellular Modem. A
list of supported USB Models can be found in the release notes and in
the Software Configuration Guide
Used for service and maintenance, the console port an RS-232 RJ-45
connector, connects the product to a serial terminal such as a PC or
ASCII Terminal (also called a dumb terminal).
Configuration settings:
• 19200 bps
• 8 bits, no parity
• 1 stop bit
• flow control off
Flashes when there are ongoing or ringing calls.
Off when there are no ongoing or ringing calls.
RJ11 analog ports located on the front panel.
WAN device (for example, a cable modem, DSL modem, or fiber
modem).
On: Connected to network
Flashing: Data is received or transmitted
Off: Not connected to network
On: Connected to network at 1 Gbps
Off: Connected to network at 10/100 Mbps or not connected to network
Description
2 • General Information
37
