Programmable Configuration Data
Table A-3
Offset
(HEX)
70
71
72
73
74
75
76
77
78
79
7A
7B
7C
7D
7E
7F
80
81
82
83
74
Static VPD Contents (continued)
Data (HEX) Field Type
0A BINARY
04 BINARY
xx
xx
BINARY
xx
xx
0B BINARY
0C BINARY
00
BINARY
01
7E
BINARY
23
10 BINARY
02 BINARY
01 BINARY
20 BINARY
20 BINARY
01 BINARY
6E BINARY
09 BINARY
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
Programmable Configuration Data
Description
EPROM CRC
When computing the CRC this field (4 bytes) is set
to zero. This CRC only covers the range as Integer
Vital Product Data CRC
(4-byte). Refer to
Calculation on page 67
Note:
Lower CRC byte for the calculation of CRC = 0x00
Upper CRC byte for the calculation of CRC = 0x1FF
# of bytes
** CRC to be filled in
Bank 1 Flash Memory Configuration Packet
# of bytes
Vendor Identifier
Device Identifier
Single device width in bits
Number of devices or sockets present
Number of interleave columns
Column width in bits
Minimum write/erase data width in bits
Flash bank number
Flash access speed in nanoseconds: 0x6E = 110 ns
Total bank size [(1<<n)*256K bytes]: 0x09 = 128
MB
.
