Introduction
Table 1-2
Function
2
I C
Flash
NVRAM
PCI_E
I/O
USB
Ethernet
Serial Interface
Timers
Watchdog Timer
16
Features List (continued)
Features
One 8 KB VPD serial EEPROM
Two 64 KB user configuration serial EEPROMs
One Real Time Clock (RTC) with removable battery
Dual temperature sensor
One SPD for memory on SO-CDIMM
Connection to XMCspan and rear transition module
128 MB soldered NOR flash with two alternate 1 MB boot sectors
selectable via hardware switch
H/W switch or S/W bit write protection for entire logical bank
4 GB NAND flash
One 512 KB MRAM extended temperature range (-40 °C to
+105 °C/-40 °F to +221 °F)
8X Port to XMC Expansion
One front panel mini DB-9 connector for front I/O: one serial
channel
Two front panel RJ-45 connectors with integrated LEDs for front
I/O: two 10/100/1000 Ethernet channels
One front panel USB Type A upright receptacle for front I/O: one
USB 2.0 channel
PMC site 1 front I/O and rear P2 I/O
PMC site 2 front I/O
One four-channel USB 2.0 controller: one channel for front panel
I/O
Four 10/100/1000 MPC8548E Ethernet channels: two front panel
Ethernet connectors and two channels for rear P2 I/O
One 16550-compatible, 9.6 to 115.2 Kbaud, MPC8548E,
asynchronous serial channel: one channel for front panel I/O
One quad UART (QUART) controller to provide four 16550-
compatible, 9.6 to 115.2 Kbaud, asynchronous serial channels:
four channels for rear P2 I/O
Four 32-bit MPC8548E timers
Four 32-bit timers in a PLD
One watchdog timer in PLD
