A.10 VPD Contents for MVME4100 Boards

The following tables describe the VPD data to be programmed into U49.
only the static VPD data and
This information is subject to change (under authority of an engineering change order). If a
difference is noted between either or these tables and your board, please contact your
support representative to determine which is accurate.
Table A-3
Offset
(HEX)
00
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
Table A-4 on page 76
Static VPD Contents
Data (HEX) Field Type
45
4D
45
52
ASCII
53
4F
4E
20
02
BINARY
00
0F BINARY
04 BINARY
00 BINARY
03 BINARY
00 BINARY
00 BINARY
Programmable Configuration Data
contains only the variable VPD data.
Description
Eye-Catcher ("SMART EC") Note: Lowest CRC
byte for the calculation of CRC.
Size of VPD area in bytes. The size is viewed as
logical; it is not the size of the EEPROM. 512 bytes
in this VPD architecture
VPD Revision Packet
# of Bytes
Board Type: Processor Board
Architecture Revision
Board Build Revision
Revision Reason Flags
Table A-3 contains
