Nand Flash Chip 2 Presence Register - SMART Embedded Computing MVME4100 Programmer's Reference Manual

Register Descriptions
CE4
CE3
CE2
CE1
RSVD
3.1.15

NAND Flash Chip 2 Presence Register

The MVME4100 provides a Presence Register for the NAND Flash device.
Table 3-18
REG
BIT
Field
OPER
RESET
C2P
RSVD
38
Chip Enable 4. If cleared, CE4 is not asserted when the device is accessed. If set,
CE4 is asserted when the device is accessed.
Chip Enable 3. If cleared, CE3 is not asserted when the device is accessed. If set,
CE3 is asserted when the device is accessed.
Chip Enable 2. If cleared, CE2 is not asserted when the device is accessed. If set,
CE2 is asserted when the device is accessed.
Chip Enable 1. If cleared, CE1 is not asserted when the device is accessed. If set,
CE1 is asserted when the device is accessed.
Reserved for future implementation.
NAND Flash Chip 2 Presence Register
NAND Flash Chip 2 Presence Register - 0xF200 001C
7 6 5
C2P RSVD RSVD
R
X 0 0
Chip 2 Present. If cleared, chip 1 is not installed on the board. If set, chip 2 is
installed on the board.
Reserved for future implementation.
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
4 3 2
RSVD RSVD RSVD
0 0 0
Register Descriptions
1 0
RSVD RSVD
0 0
