3.1.6

Interrupt Register 2

The RTC, TEMP sensor and Abort switch interrupts are OR'd together. The MVME4100
provides an Interrupt Register that may be read by the system software to determine which
device originated the interrupt. This register also includes bits that allow the interrupt
sources to be mask.
Table 3-7
REG
BIT
Field
OPER
RESET
ABORT
Status
TEMP Status TEMP Status. If cleared, the Temperature sensor output is not asserted. If set, the
RTC Status
ABORT
Mask
TEMP Mask
RTC Mask
RSVD
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
Interrupt Register 2
Interrupt Register 2 - 0xF200 0005
7 6 5
RSVD RTC TEMP
Mask Mask
R R/W
0 1 1
ABORT Status. This bit reflects the current state of the on-board abort signal. This
is a debounced version of the abort switch and may be used to determine the state
of the abort switch. A cleared condition indicates that the abort switch is not
depressed while a set condition indicates that the abort switch is asserted.
Temperature sensor output is asserted.
RTC Status. If cleared, the RTC output is not asserted. If set, the RTC output is
asserted.
ABORT Mask. This bit is used to mask the abort switch output. If this bit is cleared,
the abort switch output is enabled to generate an interrupt. If the bit is set, the abort
switch output is disabled from generating an interrupt.
TEMP Mask. This bit is used to mask the MAX6649 temperature sensor thermostat
output. If this bit is cleared, the thermostat output is enabled to generate an
interrupt. If the bit is set, the thermostat output is disabled from generating an
interrupt.
RTC Mask. This bit is used to mask the RTC output. If this bit is cleared, the RTC
output is enabled to generate an interrupt. If the bit is set, the RTC output is disabled
from generating an interrupt.
Reserved for future implementation.
Register Descriptions
4 3 2
ABORT RSVD RTC
Mask Status
R
1 0 X
1 0
TEMP ABORT
Status Status
X 0
