4.7

VPD EEPROM

The MVME4100 board provides an 8 KB dual address serial EEPROM containing Vital
Product Data (VPD) configuration information specific to the MVME4100. Typical
information that may be present in the EEPROM may include: manufacturer, board
revision, build version, date of assembly, memory present, options present, L2 cache
information, etc. The VPD EEPROM is hardwired to have a device ID as shown in
4 on page
Documentation, for additional details.
4.8

RTM VPD EEPROM

The MVME4100 RTM provides an 8 KB dual address serial EEPROM containing VPD
configuration information specific to the MVME4100 RTM. Typical information that may be
present in the EEPROM may include: manufacturer, board revision, build version, date of
assembly, options present, etc. The RTM VPD EEPROM device ID is user selectable with
the recommended value for MVME4100 as shown in
EEPROM Data Sheet listed in
4.9

Ethernet PHY Address

The assigned Ethernet PHY addresses on the MPC8548E MII management (MIIM) bus is
shown in the following table.
Table 4-5
MPC8548E
Ethernet Port
TSEC1
TSEC2
TSEC3
TSEC4
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
56. Refer to the EEPROM Data Sheet listed in
Appendix B, Related
PHY Types and MII Management Bus Addresses
Function/Location
Gigabit Ethernet port 1 routed to front panel
Gigabit Ethernet port 2 routed to front panel
Gigabit Ethernet port routed to P2
Gigabit Ethernet port routed to P2
Programming Details
Appendix B, Related
Table 4-4 on page 56. Refer to the
Documentation, for additional details.
PHY Types
BCM5482SH
BCM5482SH
BCM5482SH
BCM5482SH
Table 4-
PHY MIIM
Address
[4:0]
01
02
03
04
