Table 4-12
Device
MPC8548E
MPC8548E
PMC1
PMC2
Tsi148
USB
BCM5482S
BCM5482S
Control and Timers
PLD
QUART
USB
RTC
ICS9FG104
MPC8548E
XMCspan
4.13.1

System Clock

The system clock is driven by an oscillator. The following table defines the clock frequency.
Table 4-13
SYSCLK
66.67 MHz
4.13.2

Real Time Clock Input

The RTC clock input is driven by 1 MHz clock generated by the Control and Timers PLD.
This provides a fixed clock reference for the MPC8548E PIC timers which software can use
as a known timing reference.
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
Clock Assignments (continued)
Clock Signal
CLK_RTC
CLK_PCI
CLK_PCI1
CLK_PCI2
CLK_PCI3
CLK_PCI4
CLK2_25MHZ
CLK3_25MHZ
CLK1_25MHZ
CLK_LBP
CLK_1.8M
CLK_48MHZ
CLK_32K
CLK4_33MHZ
CLK_PCIE0
CLK_PCIE1
Clock Frequencies
Core
MXP (Platform)
1.3 GHz
533 MHz
Frequency
Clock Tree
(MHz)
Source
1
PLD
66/100
MPC9855
33/66/100
MPC9855
33/66/100
MPC9855
66/100
MPC9855
33
MPC9855
25
Oscillator/Buffer
25
Oscillator/Buffer
25
Oscillator/Buffer
MPX CLK / 8
MPC8548E
1.8432
Oscillator
48
Oscillator
32.768 KHz
Crystal
25
Oscillator/Buffer
100
ICS9FG104
100
ICS9FG104
DDR2
266 MHz
Programming Details
Qty
VIO
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+2.5 V
1
+2.5 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
+3.3 V
1
DIFF
1
DIFF
LB
33 MHz
63
