Programming Details

4.1

Overview

This chapter includes additional programming information for the MVME4100. Items
discussed include:

MPC8548E Reset Configuration on page 47
 MPC8548E Interrupt Controller on page 54
 Local Bus Controller Chip Select Assignments on page 55
 I2C Device Addresses on page 56
 User Configuration EEPROM on page 56
 VPD EEPROM on page 57
 RTM VPD EEPROM on page 57
 Ethernet PHY Address on page 57
 Flash Memory on page 58
 PCI/PCI-X Configuration on page 58
 PCI IDSEL and Interrupt Definition on page 59
 PCI Arbitration Assignments on page 60
 LBC Timing Parameters on page 62
 Other Software Considerations on page 61
 Clock Distribution on page 62
4.2

MPC8548E Reset Configuration

The MVME4100 supports the power-on reset (POR) pin sampling method for processor
reset configuration. The states of the various configuration pins on the processor are
sampled when reset is deasserted to determine the desired operating modes.
Combinations of pull-up and pull-down resistors are used to set the options. Some options
are fixed and some are selectable at build time by installing appropriate pull up/pull down
resistor combinations for the board's Bill of Materials. Each option and the corresponding
default setting are described in the following table. Refer to the MPC8548E reference
manual, listed in
79 for additional details and/or programming information.
MVME4100 Single Board Computer Programmer's Reference (6806800H19D)
Appendix B, Related Documentation,
Chapter 4
Manufacturers' Documents on page
47
