SmartNode 4740 Series (16–32 Ports) User Manual
• Digit collection, call distribution and hunt groups
• Transparent line extension
• Fallback Routing: Soft fallback to alternative route(s)

FXS Connectivity

• 2-wire Loopstart on RJ-11 or RJ21 (Telco 50-pin)
• MWI—high voltage, line reversal and FSK method
• Localization—All tones programmable (dial, ringing, busy)
• EuroPOTS (ETSI EG201188)
• Programmable AC impedance, feeding, ring and onhook voltage
• Peak Ring voltage: 87.7Vpk
• Ring voltage: 62Vrms
• Current Feed ILA: 26mA
• Talk Battery Voltage: -20V
• On-Hook voltage VOC: 51V
• Caller-ID FSK and ITU V.23/Bell 202 generation
• Long Reach FXS—10 km @ 3REN load
• Secondary Surge Protection*

FXO Connectivity (coming soon)

• 2-wire Loopstart on RJ-11 or RJ21 (Telco 50-pin)
• Programmable impedance
• Ring detection, tone detection
• Caller ID detection (FXS, DTMF)
• Connect & Disconnect supervision

Connectivity

• Two 10/100/1000Base-T Ethernet ports
• USB port
• Auto-MDIX
• DHCP Client and Server
• PPPoE Client (multi-session)
• IP Multi-Netting, VLAN, Secondary IP
• IPv4 and IPv6—Dual Stack

FXS Connectivity
