SmartNode 4740 Series (16–32 Ports) User Manual

Installing interface cables on the SmartNode device's FXS interface ports

The SmartNode comes with:
• 16, 24 or 32 FXS RJ11 analog ports (see
or
• 1 or 2 RJ21 analog port connector (see
located on the front of the device.
The FXS RJ11 interfaces are connected to analog devices via cables (see
tors (see section "Analog FXS"
For the RJ21 connectors, see the pin-outs in section
For details on the Ethernet port pinout and cables, refer to
D, "Port pin-outs" on page 52.

Connecting the power supply

Do the following to connect the main power to the Model SN4740 Series:
Do not connect the power cord to the AC Mains at this time.
Note
Installing the SmartNode 4740
figure 3 on page 19)
figure 4 on page 20)
on page 59).
"RJ21
Figure 13. Analog FXS connection
Table 5. RJ-11 socket
Pin
3
4
figure 13) terminated with RJ-11 connec-
Models" on page 54.
Signal
Ring (-)
Tip (+)
Appendix C, "Cabling"
3 • SmartNode Installation
on page 49 and Appendix
31
