SmartNode 4740 Series (16–32 Ports) User Manual
1. Insert the female end of the AC power supply cable to the mains port (see
CAUTION
2. Verify that the AC power cord included with your device is compatible with local standards. If it is not,
refer to "Contacting Patton for Assistance"
power cord.
3. Connect the male end of the power cord to an appropriate power outlet.
4. Verify that the green power LED on the rear panel is lit.
Congratulations, you have finished installing the SmartNode Enterprise Session Border Controller! Now go to
Chapter 4, "Initial Configuration"
Installing the SmartNode 4740
There are no user-serviceable parts in the power supply section
of the model SN4740 Series. Contact Patton Electronics Techni-
cal Support at support@patton.com for more information
on page 39 to find out how to replace it with a compatible
on page 33.
3 • SmartNode Installation
figure 10 on page 23).
