About this guide

This guide describes the SmartNode 4740 Series Analog High Density Gateway (16 to 32 ports) hardware,
installation and basic configuration. For detailed software configuration information refer to the
ware Configuration Guide
Audience
This guide is intended for the following users:
Operators
•
• Installers
Maintenance technicians
•
Structure
This guide contains the following chapters and appendices:
Chapter 1 on page 14 contains what you need to quickly start using the SmartNode device.
•
• Chapter 2 on page 18 provides information about SN4740 features and capabilities
• Chapter 3 on page 23 contains an overview describing SN4740 operation and applications
• Chapter 3 on page 27 provides quick start hardware installation procedures
Chapter 4 on page 33 provides quick-start procedures for configuring the SmartNode SN4740
•
Chapter 5 on page 39 contains information on contacting Patton technical support for assistance
•
Appendix A on page 42 contains compliance and regulatory information for the SN4740
•
Appendix B on page 44 contains specifications for the SN4740
•
Appendix C on page 49 provides cable recommendations
•
Appendix D on page 52 describes the SN4740's ports and pin-outs
•
• Appendix E on page 60 lists the factory configuration settings for SmartNode 4740
page 60 lists the factory configuration settings for SmartNode 4740 Series
Appendix F on page 62 describes RESET button functions for the SmartNode 4740 Series
•
Appendix G on page 67 provides license information that describes acceptable usage of the software pro-
•
vided with the SmartNode 4740 Series
For best results, read the contents of this guide before you install the SN4740.
and the available Knowledgebase, as well as the Wizard portal.
