SmartNode 4740 Series (16–32 Ports) User Manual

Introduction

This section provides pin-out information for the ports of the SmartNode.

Ethernet

Pins not listed are not used.
Note

FXS port

RJ11 Models

The FXS ports use an RJ-11 connector with 6 positions. The middle two positions 3 and 4 are used according
to table 9 and figure 19
Pins not listed are not used.
Note
Introduction
Table 7. 10/100Base-T RJ-45 socket
Pin
1
2
3
6
Table 8. 1000Base-T RJ-45 Socket
Pin
1
2
3
4
5
6
7
8
on page 54.
Table 9. RJ-11 socket
Pin
3
4
Signal
TX+
TX-
RX+
RX-
Signal
TRD0+
TRD0-
TRD1+
TRD1-
TRD2+
TRD2-
TRD3+
TRD3-
Signal
Ring (-)
Tip (+)
D • Port pin-outs
53
