Multitest 0.5dV, 1dV & 2.5dV
Service and Repair Manual
Adjust top and bottom (short) locking collars to "Factory" set limits as listed in
81.
the table below. Tighten in position using Loctite 243 on the screwthreads.
Top Collar
Bottom Collar
80.
Withdraw the limit switch/rod assembly from the
test stand
Refitting of the Limit Switch
is the reverse of the above procedure
0.5 kN Stands
50mm
60mm
Number 022-780
Issue Number: 02
1 kN Stands
50mm
60mm
Page 22 of 32
2.5 kN Stands
50mm
60mm
