Multitest 0.5dV, 1dV & 2.5dV
Service and Repair Manual
23.
Disconnect from the VIC board the
rear panel USB 4 way loom (x10)
and the RJ11 6 way loom (X3)
24.
Disconnect the digital I/O loom (352-248) rear panel (I/O) from PL1
(EXPANSION I/O) on the VIC board
25.
The complete rear panel can now be lifted out for replacement as an assembly,
or the replacement of the panel itself, or any of the connectors/looms
Refitting of the Rear Panel is the reverse of the above procedure
Number 022-780
Issue Number: 02
Page 9 of 32
