Multitest 0.5dV, 1dV & 2.5dV
Service and Repair Manual
410-836 LABEL-DV EXPANSION REAR PANEL
410-837 LABEL-DV GAUGE REAR PANEL
420-035 SCREW TAPTITE PAN POSI M3x6
420-064 SCREW CAP HEAD SKT M6x16
420-094 WASHER INT. SHAKEPROOF M6
420-095 NUT NYLOC M3
420-106 NYLON WASHER M3
420-118 SCREW CSK POZI M3x10
420-190 NUT FULL M6
420-229 NUT SELF CLINCHING M4
420-291 NUT SELF CLINCHING M3
420-613 F/F THREADED STANDOFF M3 12mm
420-622 SCREW, CHEESE, NYLON, M3X10
424-040 JACKPOST M/F M3 x 5 x 4NC
43 910-254
331-062 PILLAR M4 x 25 x M4
401-027-V01 MT-2.5 Mk2 BALLSCREW
406-281 ULTRATEST OPTO PICKUP SPACER
406-593 END CAP
408-028-F99 MULTITEST MOVING X HEAD
408-310 MULTITEST TOP X HEAD
411-002 DU BUSH 1212
411-003 DU BUSH 2030
411-118 THRUST WASHER (KOYO AS1226)
411-119 THRUST BEARING KOYO AXK1226 A
413-037 ADJUSTABLE HANDLE LEVER M8
415-022 DISC SPRING 180002
420-039 WASHER M3. 0.5. ZINC
420-053 SCREW GRUB SKT M4x10
420-063 SKT GRUB SCREW M4x4MM
420-236 M12x1 NUT LOCKING PITCH
420-246 WASHER FLAT M12 (1.5mm THK)
420-297 M4x24 DOWEL PIN
424-010 M6 LKG.COLLAR 890214
424-107 COUPLER SET SCREW STYLE 12mm
44 910-255
331-062 PILLAR M4 x 25 x M4
401-031 MT 1.0 Mk2 BALLSCREW
406-281 ULTRATEST OPTO PICKUP SPACER
408-028-F99 MULTITEST MOVING X HEAD
408-310 MULTITEST TOP X HEAD
411-002 DU BUSH 1212
411-003 DU BUSH 2030
411-118 THRUST WASHER (KOYO AS1226)
411-119 THRUST BEARING KOYO AXK1226 A
413-037 ADJUSTABLE HANDLE LEVER M8
415-022 DISC SPRING 180002
420-039 WASHER M3. 0.5. ZINC
420-053 SCREW GRUB SKT M4x10
BALLSCREW ASSY KIT MT2.5 Mk2
BALLSCREW ASSY KIT MT1.0 Mk2
Number 022-780
Issue Number: 02
1
1
2
1
1
2
2
2
1
5
2
2
2
2
(CONSISTS OF:)
1
1
2
1
1
1
2
3
5
2
1
2
2
1
2
1
1
1
2
1
1 (CONSISTS OF:)
1
1
2
1
1
2
3
5
2
1
2
2
1
