Open-Q™ 2500 Development Kit User Guide
23
22
21
20
15
List of Features itemized in the figure above:
1. DC Power supply connecter
2. Battery input header
3. USB serial debug console
4. USB Type-C connector for ADB
5. DC / Battery Power input selection switch
6. Battery configuration DIP switch
7. GPS antenna connection options and DIP switch
8. SOM Current Sense Header
9. Micro SD card connector
10. System Configuration DIP Switch
11. Camera connector
12. Auxiliary Thermistor Header
13. Haptic Header
2
1 3
19

Figure 1 - Assembled Open-Q 2500 Development Kit

Copyright Intrinsyc Technologies Corporation
4
5
6
17
18
9
Version 1.1
7
8
9
10
11
12
13
14
15
16
