Open-Q™ 2500 Development Kit User Guide
1. 3D Accelerometer and 3D Gyroscope – LSM6DSM
2. 3-axis Magnetometer – LIS2MDL
3. Barometer – LPS22HB
4. Relative Humidity and Temperature Sensor – HTS221
The STEVAL V6 sensor card has a keyed connector as shown in below and can be plugged into J1900
on the carrier board.
Figure 11 – Keyed connector on the STEVAL V6 Sensor Card

3.7.14 Audio IO Expansion Header J1600

The Audio IO expansion header J1600 is a 40-pin connecter that expose audio related signals as
described in the pinout table below.
Description Signal
NC NC

Figure 12 - Audio IO Expansion Header

Table 6 - Audio IO Expansion Header Pinout

Pin NO
J1600[1]
27
Copyright Intrinsyc Technologies Corporation
Description Signal
GND GND
Version 1.1
Pin NO
J1600[2]
