Open-Q™ 2500 Development Kit User Guide

3. OPEN-Q 2500 DEVELOPMENT KIT

3.1 Introduction

The Open-Q 2500 provides a quick reference and evaluation platform for the Qualcomm Snapdragon
Wear 2500 Platform. The development kit is suited for Android / Linux application developers,
OEMs, consumer manufacturers, hardware component vendors, camera vendors, and wearable
product designers to evaluate, optimize, test and deploy applications that can utilize the Qualcomm
Snapdragon Wear 2500 Platform technology.

3.2 Development Platform Notice

This development platform contains RF/digital hardware and software intended for engineering
development, engineering evaluation, or demonstration purposes only and is meant for use in a
controlled environment. This device is not being placed on the market, leased or sold for use in a
residential environment or for use by the general public as an end user device.
This development platform is not intended to meet the requirements of a commercially available
consumer device including those requirements specified in the European Union directives applicable
for Radio devices being placed on the market, FCC equipment authorization rules or other
regulations pertaining to consumer devices being placed on the market for use by the general public.
This development platform may only be used in a controlled user environment where operators have
obtained the necessary regulatory approvals for experimentation using a radio device and have
appropriate technical training. The device may not be used by members of the general population or
other individuals that have not been instructed on methods for conducting controlled experiments
and taking necessary precautions for preventing harmful interference and minimizing RF exposure
risks. Additional RF exposure information can be found on the FCC website at
http://www.fcc.gov/oet/rfsafety/

3.3 Anti-Static Handling Procedures

The Open-Q 2500 Development Kit has exposed electronics and chipsets. Proper anti-static
precautions should be employed when handling the kit, including but not limited to:
• Using a grounded anti-static mat
• Using a grounded wrist or foot strap.

3.4 Development Kit Contents

The Open-Q 2500 Development Kit comes with Android software pre-programmed and includes the
following:
o Open-Q 2500 SOM with the Snapdragon 2500 (APQ8009W) processor
o Mini-ITX form-factor carrier board
o AC power adapter

3.4.1 Important Locations

See the diagram below for the locations of key components, interfaces, and controls.
