scanCONTROL Output Unit
7.3
After having installed the required wiring of the ports of the scanCONTROL Output Unit, you have to param-
eterize the measuring system according to your measurement task to get the desired signals at the digital
and analog output ports.
Alternatively scanCONTROL Output Unit can be connected simultaneously to the PC and to the sensor.
When the parameterization is finished, save the settings to a user mode of the sensor.
scanCONTROL Configuration Tools > Menu Parameters > Save parameters to scanCONTROL...
Refer to scanCONTROL Configuration Tools, Chapter 3.14.4.
scanCONTROL 2910/2960 and the output unit operate now as an independent measuring system and the
signals set are output via the ports.
7.4
7.4.1
Micro-Epsilon art. no. 6414073
Consists of
- OU-Fieldbus Coupler/Ethernet
- OU-Filter module
- OU-Bus end terminal
scanCONTROL 29xx

Commissioning scanCONTROL Output Unit

Connect the sensor to the PC using the Ethernet cable.
Parameterize the measuring system using scanCONTROL Configuration Tools and assign the desired
signals to the digital and analog output ports.
Exit scanCONTROL Configuration Tools and disconnect scanCONTROL 2910/2960, PC and if necessary
the scanCONTROL Output Unit.
Connect the scanCONTROL 2910/2960 sensor to the Output Unit by using the Ethernet cable.

Specification of the Components

Output Unit Basic
