Mounting and Installation
Recommended
attachment point
MR = Measuring range
SMR = Start of measuring range
MMR =Mid of measuring range
EMR = End of measuring range
Fig. 12 Dimensional drawing scanCONTROL 29xx-25 sensor, dimensions in mm (inches), not to scale
scanCONTROL 29xx
M5 10 (.39)
ø 5.2 x 90°
(on both sides)
Recommended
attachment point
85.75 (3.38)
79 (3.11)
75.5 (2.97)
9 (.35)
3 (.12)
0
29.3 (1.15)
29.1 (1.15)
25 (.98)
23.4 (.92)
23.2 (.91)
(~12.9°)
96 (3.78)
89 (3.50)
0
MR extended ≥ 53 (2.09)
53 .5 (2.11) SMR
66 (2.60) MMR
78.5 (3.09) EMR
MR extended ≤ 79 (3.11)
