Mounting and Installation
5.3
- Only use shielded cables from the accessories for all connection
- Connect the cable shields to the potential equalization PE on the evaluation unit (control cabinet, PC hous-
- Lay all connection cables in accordance with the generally applicable measuring technology regulations,
- The minimum bending radii of the recommended cables for flexible laying must not be less 80 mm.
- MICRO-EPSILON recommends the use of the optionally available power supply PS2020, DIN rail mount-
The sensor must only
5.4
be connected to the
peripheral equipment
when disconnected
from the power supply,
i.e only when the sup-
ply voltage is switched
off.
scanCONTROL 29xx

Installation Instructions

ing, connector housing) and avoid ground loops.
i.e. for example not directly next to pulse-carrying lines, preferably in a separate cable duct.
ing, input 230 VAC, output 24 VDC/2.5 A.

Getting Ready for Operation, Commissioning

Mount the sensor according to the installation
Connect the sensor to the Ethernet cable.
Connect the sensor to downstream display or monitoring units and to the power supply.
Switch on the power supply.
cables, see A 1.2.
instructions, see 5.1.
