Mounting and Installation

5.
5.1
- using 2 or 3 screws M5, screwed directly
- using 2 or 3 screws M4, screwed pushed through
Depending on the installation position it is recommended to determine the position of the sensor for example
by adjusting screws on the specially marked attachment points.
The pin hole ø3H11 is intended for a position locking pin. The sensor can be mounted reproducible and
replaceable together with an attachment
Pay attention to careful handling during mounting and operation.
> Damage to or destruction of the sensor
The laser beam should strike the target surface at right angles. Otherwise, inaccurate measurements cannot
be excluded.
Bolt connection
Bolt length
33 mm
Direct fastening
Screwing depth
min 8 mm, max 10 mm
Fig. 10 Mounting conditions
The bearing surfaces surrounding the fastening holes (through-holes) are slightly raised.
Mount the sensor only to the existing through-holes on a flat surface. Clamps of any kind are not permitted.
Do not exceed torques.
> Inaccurate, erroneous measuring values
scanCONTROL 29xx
Mounting and Installation

Attachment and Mounting

The mounting dimensions refer to the dimensional drawings.
Mount the sensor by means of screws type M5 or by means of through bores for M4 with the screws
from the accessories.
Screw
M4 x ISO 4762-A2 A 4.3 ISO 7089-A2 2 Nm (µ = 0,12)
Screw
M5 x ISO 4762-A2 3.5 Nm (µ = 0.12)
point, see Fig. 12, see Fig. 13, see Fig. 14.
Washer Torque
Torque
