MICRO-EPSILON scanCONTROL 29 Series Operating Instructions Manual page 24

Mounting and Installation
Recommended
attachment point
Fig. 11 Dimensional drawing scanCONTROL 29xx-10/BL sensor, dimensions in mm (inches), not to scale
SMR = Start of measuring range
MMR = Mid of measuring range
EMR = End of measuring range
scanCONTROL 29xx
M5 10
5.2 x 90°
(on both sides)
Recommended
attachment point
85.75 (3.38)
79 (3.11)
75.5 (2.97)
9 (.35)
3 (.12)
22.4 (.88)
Z
96 (3.78)
89 (3.50)
0
10 (.39)
9.6 (.38)
SMR
56.5
MMR
10.4
EMR
(2.22)
(6.4°)
Page 24
