Power Supply - MICRO-EPSILON scanCONTROL 29 Series Operating Instructions Manual

Mounting and Installation
5.2.2
Connector multifunction
The multifunction
Range: 11 V – 30 V (nominal value 24 V) DC; load maximal 500 mA
socket must only
The supply voltage is protected against reverse polarity.
be connected when
the power supply is
The cable shield is connected with the connector housing and should be connected to the protective con-
switched off.
ductor PE of the power supply.
> Damage to or
The shielded multifunction cable PCR3000-x is recommended.
destruction of the
sensor
The supply voltage for the scanCONTROL 29xx measuring device should come from a 24 V power supply,
which is only used for measuring equipment and not simultaneously for drives, contactors or similar pulse
interference sources. Use a power supply with galvanic isolation.
scanCONTROL 29xx

Power Supply

socket, see Fig. 16,
pin assignment, see Fig. 17.
Page 30
