Operation of the Sensor with a PC
6.3
6.3.1
The following minimum system specification is necessary for the operation of the scanCONTROL software
packages:
scanCONTROL Configuration Tools
- Windows 7, Windows 8 or 8.1, Windows 10 (each 32 bit and 64 bit)
- 1-GHz or faster (32 bit and 64 bit) / min. 1 GB RAM
- Screen resolution: 1024 x 768
scanCONTROL 3D-View
- Windows 8 or 8.1, Windows 10 (each 64 bit)
- 1-GHz or faster prozessor (64 bit) / min. 1 GB RAM
- Screen resolution: 1024 x 768
- Graphic card / GPU with OpenGL 3.1 or higher
To be able to use the software the following steps must be followed:
1. Install the Ethernet interface hardware, if not already installed.
2. Install the software.
3. Connect the scanCONTROL 29xx measuring system to the PC via Ethernet.
6.3.2
Proceed as follows in order to connect scanCONTROL 29xx via Ethernet with the PC.
This may take a few seconds.
The system is now ready to operate the scanCONTROL 29xx measuring system with the scanCONTROL
software packages.
scanCONTROL 29xx

Installation

Requirements

Connecting scanCONTROL 29xx to the PC

Finish the installation of the software completely.
Connect scanCONTROL 29xx via the Ethernet interface to the PC and switch on the power supply.
Please wait until the scanCONTROL 29xx device is recognized by the PC.
