Mounting and Installation
Due to the high data rate, we recommend using a high-quality Ethernet PC plug-in card, for example Intel-
Pro/1000 PT. The sensors are to be preferably connected directly to the network connection or by means of a
high-quality switch. A hub would result in a massive data collision and cannot be used. The PC should have
one or more network cards only for the sensors.
The operation of the sensor via Ethernet does not require any additional driver installation. However, the net-
work settings have to be done correctly:
- If several network cards are used, they have to belong to different networks, for example different Class-C-
scanCONTROL 29xx
supports Power over
- The sensor supports an automatically, sensor-adapted IP address in the link-local-net (169.254.x.x). No
Ethernet. If the sen-
sor is connected to
- The sensor supports the DHCP protocol. This setting is activated by default and has priority over the
a network adapter/
switch that is capable
- A fixed IP address can be assigned.
of POE and if you also
use the power supply - Various network settings (e.g. firewall or packet filters) can interfere with communications with the sensor.
of the multifunction
- We recommend using a packet size of 1024 bytes/packet (payload), because network components sup-
port, these two power
supplies have to be
galvanically isolated.
Use the program sensorTOOL for network configuration. This program is available online at
https://www.micro-epsilon.de/service/download/software.
scanCONTROL 29xx
sub networks, however they may not belong to the same Class-B sub network.
collision check is performed.
retrieval in the link-local-net.
port such packages by default. The sensor supports jumbo frames up to 4096 bytes/packet (payload), but
then all the network components must also support jumbo frames of this size.
