XOR
Syntax
Operation
Data Types
Description
Performs a bitwise logical EXCLUSIVE OR of the source operand specified by op2 and the destination
operand specified by op1. The result is then stored in op1.
Flags
E
*
E Set if the value of op2 represents the lowest possible negative number. Cleared otherwise.
Used to signal the end of a table.
Z Set if result equals zero. Cleared otherwise.
V Always cleared.
C Always cleared.
N Set if the most significant bit of the result is set. Cleared otherwise.
Addressing Modes
Mnemonic
XOR
XOR
XOR
XOR
XOR
XOR
XOR
Logical Exclusive OR
XOR
(op1)
WORD
Z
*
Rw , Rw
n m
Rw , [Rw ]
n i
Rw , [Rw +]
n i
Rw , #data
n 3
reg, #data
16
reg, mem
mem, reg
ST10 FAMILY PROGRAMMING MANUAL
op1, op2
<-- (op1) ⊕ (op2)
V
0
Format
50 nm
58 n:10ii
58 n:11ii
58 n:0###
56 RR ## ##
52 RR MM MM
54 RR MM MM
C N
0 *
Bytes
2
2
2
2
4
4
4
