OPR/STBY
Short press for switching betwen STBY and OPERATION mode.
-
ON/OFF
Long press (1 sec.) for switching the PA ON (tube heating first), 2 seconds for PA OFF. Do NOT
use the green button for switching the PA OFF as first! Every time use ON/OFF button as first to give chance for
cooling the tube and inside area of the PA.
5.2.

OM2000A+ control

Turn ON the Main switch and the home screen will lights up. In the bottom line touch buttons are visible
Remember that the home screen is active for some information and settings , while PA is still OFF!
BAND
Touch the left side of BAND button to go down, touch the right site to go up with band displayed above the
button.
ANTENNA
Transmitting antenna choice. Functional ONLY when the antenna switch is programmed and antennas are defined
(see next parts). It allows switching between antennas authorized for the current band. An external antenna
switch is controlled by BCD code at the ANT/BPF output.
INFO
Information display shows basic information about the PA: serial number, software version, time ON, tube serial
number and nominal Main voltage. Some of them manufacturer can requested in case of any failure, etc.
