OM POWER OM2000A+ Manual page 24

This means not programmable setting of the primary voltage. It is just information for the processor,
which protects the permitted limits ( up or down) for a given value of the primary voltage (protection
circuit).
MEAS pressing shows
Instantaneous values of the basic parameters
Type of supported TCVR and working
are displayed.
frequency are visible on the display.
You can FREEZE the screen and measure
AGAIN.
Three different bar graphs can be defined
Type of supported TCVR and working
using BARG1, BARG2 or BARG3 button.
frequency are visible on the display.
Press BARG1.
Green graph may show one of the 8
Type of supported TCVR and working
parameters. Scroll to request parameter and
frequency are visible on the display.
press SAVE. Screen jumps back.
this screen.
AUTO LED is ON.
AUTO LED is ON.
AUTO LED is ON.
24
