OM POWER OM2000A+ Manual page 22

Another display appears, if CAT was defined but TCVR is not connected with the PA (CAT cable). See the following
pictures.
FREQ button has two functions. It allows to
Type of supported TCVR and working
display working frequency or active band
frequency are visible on the display.
segment.
Also in this case frequency will be read directly
from the TCVR in operation mode.
Type of supported TCVR and working
frequency are visible on the display.
Use ANTENNA (left/right) to select one of
preprogramed antenna for that band.
Menu display allows to go deeper to the
Type of supported TCVR and working
SETTINGS mode, MEASuring mode or to
frequency are visible on the display.
SERVICE mode.
Press SETTING button.
AUTO LED is ON.
AUTO LED is ON.
AUTO LED is ON.
