OM POWER OM2000A+ Manual page 35

Side view on the opened OM2000A+
HV Transformer
Remove the upper lid first. On the right side of the PA, next to the HV transformer there are two PCBs mounted.
On the left upper side of the front (Switch-ON) board connector J6 is located.
AC selector range can be changed in the production according to the specific conditions in individual
countries. Default settings is 220V – 240V / 50 Hz for EU market and 230V – 250V / 60Hz for US market.
If you need different settings in the range of 200 – 260V, this should be specified in the order!
AC Selector
flat screwdriver or finger and press carefully the white
stick to release contact and move upper end of the white
jumper to the proper position, if necessary
Jumper must be connected between bottom contact and
one of remaining contacts. AC voltage is marked next to Type of supported TCVR and working
every contact.
frequency are visible on the display.
Use
.
AUTO LED is ON.
35
