7.5.3 Remote Control without own IP Address, behind a router

If you need to change the OM2000A+ connection setings for some reason, use point 7.5.1 writen above.
Change router´s settings
Open Firewall Settings (depends on router software, can be called Forwarding, Port Forwarding, or something
similar). As Server IP enter the OM2000A+ IP Address, 192.168.1.211 if you haven't changed it, or the one you
changed to in point 7.5.1. Private port should be 10001 in default, or the one you changed to in point 7.5.1. Some
routers THEY don't have a separate Public Port settings. If you got, enter a free port number (usually the default
10001 is free and usable). Check the Enable box too. When done, click OK (or Save).
Open up a WEB browser and enter the routers´s
internal IP Address ( usually 192.168.1.1)
Type of supported TCVR and working
frequency are visible on the display.
An authentication window WILL APPEAR. You need
to enter the routers login and password. Usualy a
router´s default login is "admin" or "
Type of supported TCVR and working
administrator" and default password "admin"
frequency are visible on the display.
or an empty field.
AUTO LED is ON.
AUTO LED is ON.
46
