SECTION 2
2. Specifications
2.1. Physical Dimensions
When the WiZos are removed from their packaging, it is important to remember the
following:
The WiZos are ready to be used; they have just not been configured or added to a
network. Configuration is what the user / installer needs to do.
31mm
2.2. Technical Specifications
Input voltage
Current consumption (mains)
Battery charger current output
Maximum number of operations per day
Duty cycle - Mains present
Motor power supply
Current consumption (motor at rated load)
Input / Output sink currents (Max. accessory current draw)
I/O 1-4
I/O 5 and 6
181mm
FIGURE 1. D5 SMART PHYSICAL DIMENSIONS
2,3
page 9
275mm
90V - 240V AC +/-10% @ 50Hz
200mA
1.3A
150
3,6
50%
Battery-driven
(Standard Capacity - 2x12V)
13A
100mA (12/24V)
3A (12/24V) 10sec Pulse
SPECIFICATIONS
1
TABLE 1
