SECTION 7
7.1.2. Minimum Clearances
Below are site plan examples illustrating the minimum clearances required when
installing the D5 SMART.
Pillar
80mm
Foundation
Theft-deterrent Cage
Foundation
Trench
Gate Rack
FIGURE 10. MINIMUM CLEARANCES - SIDES
Gate Rack
Most extreme path of
Trench
FIGURE 11. MINIMUM CLEARANCES - FRONT
page 19
OPERATOR INSTALLATION
80mm
the Override Lever
www.centsys.com
Pillar
D5 SMART
Trench
